Fence Panel Rombo Mini | Oak

• Distinctive rhomboid design for a modern architectural look

• Made from double-galvanized, pre-painted steel

• Durable in extreme weather – from –50°C to +120°C

• Zero maintenance – no rust, no repainting

• Full privacy with stylish aesthetics

• 15-year warranty and 50-year lifespan

1. “Slat” Profile

How it’s installed: Fitted between the two vertical “U” profiles,
mounted top‑to‑bottom, and secured in four places (front and back) using pop
rivets.

Purpose: Provides the panel’s visual character, ensures privacy, allows
air circulation.

2. Vertical “U” Profiles

How it’s installed: Secured directly to the supporting posts (metal,
concrete, or brick) using included screws or anchors. Pre‑drilled holes allow
quick and precise alignment of the slat profiles, saving installation time and
reducing positioning errors.

Purpose: Form the panel’s side frame, support and guide the installation
of the slat profiles, conceal the slat ends, and provide structural stability.

3. Horizontal “U” Profile

How it’s installed: Placed at the very end of the panel assembly, over the
top ends of the two vertical profiles and, if applicable, a reinforcing
profile. It’s drilled through together with those elements and fastened in four
spots using pop rivets.

Purpose: Aesthetic finish that visually closes the panel’s top;
structurally, it stiffens the assembly and strengthens the connection between
the vertical and slat profiles.

4. Reinforcing Profile

How it’s installed: Mounted centrally on the back of the panel. It’s
automatically included for wider panels: one profile for widths over 1.30 m,
two profiles for widths over 2.10 m. Installed on the back by drilling and
riveting into each slat. At the bottom, it's additionally anchored via an L‑shaped
bracket fixed to the base or foundation.

Purpose: Critically reinforces the panel and prevents slat buckling in
wider panels, ensuring a balanced and solid structure.

5. Pop Rivets

Fastening elements used to attach panel components to each other—such as
the slat profile, reinforcing profile, or horizontal “U” profile.

6. Self‑Tapping Screws

Used to attach the vertical “U” profiles to metal posts without the need
for pre-drilling.

7. Wall Anchors

Fixing system for concrete or brick posts: the anchor is inserted into the
substrate material, and the profile is then fixed with screws at the
appropriate points.

8. Mounting Bracket

An L‑shaped metal bracket used for additional fastening of the reinforcing
profile at the base, securing it firmly to the foundation.

• Material Type: Galvanised steel sheet, pre-painted and double zinc-coated with a durable polymer finish.

• Fence Model: Rombo Mini

• Panel Height: 11.3 cm

• Color: Wood Imitation Oak

• Finish: Matte

• Material Thickness: 0.50 mm

• Panel Weight: 15–35 kg (depending on size)

• Main Fastening Element: Pop Rivets

• Pop Rivet Color: Brown

• Pop Rivet Size: 4 × 10 mm

• U-Profile Width: 2.3 cm

• Warranty: 15 years
